Toe Puff Counter Material is a structural stiffening sheet placed between the outer shoe material and the inner lining at the heel and toe box. Its primary function is to give shoes a clean, permanent shape and prevent deformation during daily wear.
Product Parameters
|
Item |
Specification |
|
Material |
100% Non-woven Polyester |
|
Thickness |
0.4–1.5mm (Tolerance ±0.03mm) |
|
Sheet Size |
1m × 1.5m / 0.9m × 1.5m |
|
Color Options |
Raw White, Charcoal Black, Customized Colors |
|
Application |
Shoe Toe Puff |
|
Key Performance |
Abrasion Resistant, Flex Resistant, Heat-Setting Retention |
|
Processing Compatibility |
Heat Activation: 90–130°C; Suitable for PU Glue, Hot Melt Film & Solvent Cement |
|
Compatible Uppers |
Genuine Leather, PU/PVC Synthetic Leather, Suede, Technical Canvas |
|
Cutting Performance |
Suitable for Hydraulic & Laser Cutting; Clean Skiving Down to 0.1mm |
|
MOQ & Supply |
MOQ: 1000 Sheets; Origin: Fujian, China |
Key Features
Elastic Recovery: Prevents toe-box collapse during shoe-lasting, retaining the original shape under heavy pressure.
Abrasion Resistance: Exceeds 50,000 dry/wet Martindale cycles (ISO 20344) without fiber tearing or surface breakdown.
Flex Fatigue Resistance: Withstands continuous dynamic flexing without structural cracking or shape distortion.
Moisture Resistance: Hydrophobic resin matrix prevents material swelling and adhesive failure caused by internal sweat.
Thermal Stability: Excellent thermal stability during hot-press molding ensures precise shoe sizing.
Customization & OEM Support
High-Precision Gauge Skiving: Delivers custom thickness from 0.4mm to 1.5mm with a strict tolerance of ±0.03mm.
Custom Format Converting: Supplies tailored roll widths and sheet dimensions optimized for automated CAD/CAM cutting tables.
Pre-Applied Thermal Adhesives: Offers factory-coated EVA or TPU hot-melt glue backings with customized activation temperatures.
OEM Die-Cutting & Printing: Provides ready-to-use pre-cut toe puff components with custom brand printing on release paper.
Supply Capacity
Scalable Output: 2,000,000+ sheets annual capacity from our Quanzhou facility for high-volume supply security.
Flexible Trial Orders: Low-risk production scaling starting at a minimum order quantity (MOQ) of 1,000 sheets.
Stocked Buffer Inventory: 300+ standard material styles and thicknesses maintained for immediate factory dispatch.
Lead Times: Standard orders processed, packed, and delivered to port within 10 to 15 business days.
Emergency Capacity Reserve: Dedicated backup production lines reserved to accommodate seasonal peak order surges.
After-Sales Service
48-Hour Sample Dispatch: Express shipment of A4 or full-sheet sample swatches for laboratory evaluation.
Non-Conforming Material: Direct 100% replacement or account credit policy for any material failing agreed specs.
Turnkey Export Logistics: Full management of export documentation, shipping bookings, and customs clearance.
Compliance & Factory Audits
In-house lab verification of tensile, peel, and heat-bonding strength per production lot.
Real-time PLC optical defect sorting system eliminates surface flaws during rolling.
Serial tracking links raw polyester intake directly to final shipped sheet lots.
Eco-compliant needle-punching process eliminates hazardous emissions and waste.
FAQ
Q: What advantages does this material have compared with traditional fabric toe puff sheets?
A: Compared with conventional fabric-based reinforcement sheets, polyester non-woven construction provides more stable thickness, better heat-setting performance, and improved shape recovery.
Q: Which specific third-party lab (SATRA, SGS, or similar) verifies the ISO 20344 abrasion testing?
A: Testing is conducted per ISO 20344 methodology using in-house lab equipment calibrated against SATRA reference standards; independent third-party verification through SATRA or SGS can be arranged upon request for buyers requiring external certification. If your procurement process requires an official third-party report from SATRA or SGS, we can arrange for testing at any time.
Q: Does the recommended activation temperature vary depending on whether the upper material is genuine leather versus synthetic leather or canvas?
A: Yes, genuine leather typically activates well at 100-115°C due to its natural thermal conductivity, while PU/PVC synthetic leather and technical canvas may require slightly higher settings within the 115-130°C range.
Q: What is the claim window for the 100% replacement guarantee if a batch fails specifications after arrival?
A: Buyers must submit a claim with test evidence within 15 days of port arrival, after which the 100% replacement or account credit is processed within 10 business days upon verification.
Q: When should buyers choose the pre-applied EVA hot-melt backing versus the TPU hot-melt backing?
A: EVA backing is recommended for standard cemented construction requiring moderate bond strength at lower activation temperatures, while TPU backing suits higher-stress applications like safety boots requiring stronger.
